23
Option [70]: Automation Common Event Code -
Default [00]
Some central station software packages are unable to
process an alarm using the event codes listed in the
DRL3 Decoding Library. Where a central station monitors
thousands of accounts belonging to different companies,
the same reporting codes may have different meanings
for different companies. Because of this, the individual
event codes in Options [30] through [5F] cannot accu-
rately represent the alarm condition. To overcome this,
Option [70] may be programmed as indicated below:
Program Operation:
00 - Use individual event codes to computer.
20, 30-39 & 41-5A - Use common event codes (space,
0-9, A-Z). When using common event codes, DSC rec-
ommends that either hexadecimal code '5A' (ASCII 'Z') or
hexadecimal code '41' (ASCII 'A') be used. The 'Space'
character (Hex 20) can be used as the common event
code with certain automation software packages to
avoid account code database changes when switching
over from other brand receivers to the Sur-Gard receiver.
B0-DF ('0'-'9', 'A'-'Z' with the most significant bit set).
This range will function in the same way as 30-39, 41-
5A, with the exception that, for the Superfast Ademco
Format, the Printer Message text will not be outputted.
For example: "01-002-1234-A4-".
Option [71]: Library Select - Default [04]
Determines how to use Printer Words Options.
00 No printer words.
01 Printer words options used for 1-digit reporting code for-
mats only; other will use pre-defined library.
02 Printer words options used for 2-digit reporting code
formats only; other will use pre-defined library.
03 Printer words options used for 3-digit reporting code
formats only; other will use pre-defined library.
04 Printer words options used for 1-digit and 2-digit report-
ing code formats only; other will use pre-defined library.
05 Printer words options used for 1-digit, 2-digit and 3-
digit reporting code formats.
NOTE: Option [71] is ignored when using SIA, ITI,
Contact-ID, ACRON, MODEM II, MODEM IIE, MODEM
IIIa², FBI SuperFast, BFSK, ADEMCO Super Fast and SK
FSK1, 2 formats.
Option [72]: SIA Option - Default [00]
This option is a bit selectable Option meaning some or
all of these choices may be enabled. For example, to
enable "Force SIA Zone Number", and "Convert Pulse for-
mats to SIA", set Option[72]=05. To enable only "Con-
vert Pulse to SIA" and "Convert BFSK to SIA" set
Option[72]=0C.
Bit0 - Force SIA Zone Number.
The receiver will decode SIA Alarms sent without Zone
numbers and add '00' as the zone number to the auto-
mation output:
Example: [#1234|NriBA] becomes [#1234|NriBA00]
Bit1 - Convert SIA Account A's.
Any Account Digits received as 'A' will be converted to '0'.
Example: [#A123|NriBA01] becomes [#0123|NriBA01]
Bit2 - Convert Pulse formats to SIA.
All Pulse Format Printer and Computer outputs will be
converted to a SIA format, in a two step conversion pro-
cess.
The automation Output will use the Protocol ID of 'R'.
First the type of alarm is determined by Options[30]-
[5F], [70].
Secondly the type of alarm is mapped to a SIA output as
per the following table.
Example:
12341 becomes '1234 A 1' becomes [#1234|NBA1]
Values programmed in Options[30]-[5F],[70] other than in
this table will default to UAxx for Undecoded Alarm.
Bit3 - Convert BFSK format to SIA.
The BFSK outputs will be converted to a SIA format. The
automation Output will use the Protocol ID of 'R'.
When this option is enabled it has precidence over the
BFSK RS232 Option[A4]. The Accounts 3/x to 4/x
Option[76] may be used to insert a leading 0 to the
account code.
Example:[#123|NFA1]
Option [73]: DSP Input and Ouput - Default [13]
The upper nibble will set the input sensitivity of the DSP,
whereas, the lower nibble of the option will set the out-
put level. This option should be left at the default value
60
61
62
66
64
65
66
F2
OA
14
1E
63
62
E5
PERIODIC TEST REPORT
FIRE ALARM
PANIC ALARM
BURGLARY
CLOSING
OPENING
SERVICE
Option Value Word
60
61
62
66
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
F2
OA
14
1E
63
62
E5
00
E4
61
F2
C6
C7
E6
50
A6
PERIODIC TEST REPORT
FIRE ALARM
PANIC ALARM
BURGLARY
CLOSING
OPENING
SERVICE
MEDICAL*
MESSAGE
RESTORE
PERIODIC TEST REPORT
GROUP CLOSING
GROUP OPENING
ZONE BYPASS
SYSTEM TROUBLE
CANCEL
*Use only with Model System III CE.
System III CE is not UL Listed.
Value Codes SIA
41
42
43
46
48
4F
4D
50
52
54
5C
62
66
68
6D
70
74
7C
A
B
C
F
H
O
M
P
R
T
\
b
f
h
m
p
t
|
BA
BA
CL
FA
HA
OP
MA
PA
BR
TA
OC
BR
FH
HH
MH
PH
TH
UB
