Sur-Gard System III - Appendix F - DRL3 Communication Formats

40
Appendix F - DRL3 Communication Formats
NAME HANDSHAKE DATA BAUD FORMAT EXTENDED KISS OFF
Acron * 1400/2300Hz DTMF DTMF 3/8, 4/8 NO 1400/2300Hz
Ademco Express Dual Tone DTMF DTMF 4/1(option), 4/2 NO 1400Hz
Ademco Slow 1400Hz 1900Hz 10bps 3/1,4/1(or 3/2),4/2 NO 1400Hz
Ademco Slow 1400Hz 1900Hz 10bps 4/2,4/1,3/1 YES 1400Hz
Contact ID Dual Tone DTMF DTMF 4/2/1/3/2/3 NO 1400Hz
Contact ID 10 Digit Dual Tone DTMF DTMF 10/2/1/3/2 NO 1400Hz
FBI Super Fast 2300Hz DTMF DTMF 4/3/1 NO 2300Hz
Franklin 2300Hz 1800Hz 20bps 3/1,4/1(or 3/2), 4/2 NO 2300Hz
Franklin 2300Hz 1800Hz 20bps 4/2,4/1,3/1 YES 2300Hz
ITI ITI FSK 110/300 Baud - NO ITI
Modem II Modem II FSK 110 Baud FSK NO Modem II
Modem IIE Modem II FSK 300 Baud - NO Modem IIE
Modem IIIa
2
Modem II FSK 300 Baud - NO Modem IIIa
2
Radionics 2300Hz 1800Hz 40bps 3/1,4/2 NO 2300Hz
Radionics 2300Hz 1800Hz 40bps 4/2,3/1 YES 2300Hz
Radionics 2300Hz 1800Hz 40bps 3/1+parity NO
4/2+parity
2300Hz
Radionics 2300Hz 1800Hz 40bps 3/1+parity
4/2+parity
YES 2300Hz
RadionicsBFSK 1400Hz FSK 42 Baud 3/2 NO 1400Hz
RadionicsBFSK 2300Hz FSK 42 Baud 3/2 NO 2300Hz
S.F. Ademco Dual Tone DTMF DTMF 4/8/1 NO 1400Hz
S.F. Ademco Dual Tone DTMF DTMF 4/8/1 + Checksum NO 1400Hz
Sescoa S. Speed 2300Hz 1800Hz 40bps 4/3+Checksum NO 2300Hz
Sescoa S. Speed 2300Hz 1800Hz 40bps 4/3+Checksum ID O/C 2300Hz
SIA FSK
Level 1, 2, and 3.
SIA FSK 110bps/
300bps
- - tonal, data ACK
Silent Knight Fast 1400Hz 1900Hz 14bps 3/1,4/1 (or 3/2), 4/2 NO 1400Hz
Silent Knight Fast 1400Hz 1900Hz 14bps 4/2,4/1,3/1 YES 1400Hz
Silent Knight FSK 0 1400/2300Hz FSK 110 Baud 4/1 NO 1400/2300Hz
Silent Knight FSK1 2300Hz FSK 110 Baud 4/2, 5/2, 6/2 NO 2300Hz
Silent Knight FSK1 1400/2300Hz FSK 100 Baud 4/2 NO 1400/2300Hz
Silent Knight FSK2 2300Hz FSK 110 Baud SIA equiv. NO 2300Hz
Silent Knight FSK2 1400/2300Hz FSK 100 Baud 4/2 NO 1400/2300Hz
Sur-Gard 2300Hz DTMF DTMF 4/1,4/2,4/3 NO 2300Hz
Sur-Gard Dual Tone DTMF DTMF 4/1,4/2,4/3 NO 1400Hz
Sur-Gard 2300Hz DTMF DTMF 4/3+Checksum NO 2300Hz
Sur-Gard Dual Tone DTMF DTMF 4/3+Checksum NO 1400Hz
DMP Serial 1 DMP FSK 300 Baud DMP NO DMP
DMP Serial 3 DMP FSK 300 Baud DMP NO DMP
Varitech 2300Hz FSK 110 Baud 4/1,4/2 NO 2300Hz
Scantronics 1400Hz, Dual
Tone
DTMF DTMF 4/8/1,4/16/1,2/8/1,3/8/1
6/8/1,6/16/1,2/16/1,3/16/1
NO 1400Hz
Adcor 2300Hz Pulse Pulse 3/1,3/2 NO 2300Hz
Westec 1,2,3,5,6 Westec DTMF DTMF Westec NO Westec
Surtec * Surtec DTMF DTMF Surtec NO Surtec
CFSK * CFSK FSK 300 Baud 6/2 NO CFSK
Telenot/Telim* 2100 Hz FSK FSK 10bps FSK NO FSK
