Appendix A - CPM3 Internal Status Messages
Please refer to the System III Installation Manual.
Appendix B - DVACS Events
DVACS Generated Events
DVACS events generated on DVACS panels connected through the
T-LINK TL250/TL300 will follow the same protocols used on the SG-
DVL2A product.
DVACS Alarms Examples
Example 1 (DVACS with receiver set as 1 digit line number)
Example 2 (DVACS with receiver set as 3 digits line number)
SIA DVACS Alarms Examples
Example 1 (DVACS with receiver set as 1 digit line number)
Example 2 (DVACS with receiver set as 3 digits line number)
Additional Events:
In the case of the T-LINK TL250/TL300 transmitter not receiving polls
response from the panel, the T-LINK will generate the events previ-
ously generated by the SG-DVL2A for DVACS panel and restoral.
SIA
Standard
NOTE: The SG-DRL3-IP will use 10-digit account identifications in
it's IP table for DVACS transmitters. The first four digits represents
the receiver and line number originally used on the SG-DVL2A and
are programmed as the first four digits of the T-LINK account (refer
to Appendix F).
If the automation protocol in the form of 1RRL, 3RRL is required
when using the DRL3-IP in the DVACS configuration, set:
• DRL3-IP Option [11] =1
• CPM3 Options [10] & [11] = 03
Printer:
01 Nov 2004-11:38:22-01/02-SG -01-1-001--Burgl Alm Zn#02
Computer:
1011 001 A 02
Printer:
01/02-SG -01-001-014--Burgl Alm Zn#13
Computer:
101001 014 A 13
Printer:
01 Nov 2004-13:50:51-01/02-SG -01-1-456--Fire Alm Zn999
Computer:
3011 456FA 999
Printer:
01 Nov 2004-13:51:03-01/02-SG -01-001-456--Medical Alm
Zn001
Computer:
301001 456MA 001
Printer:
01 Nov 2004-13:50:51-01/02-SG -01-1-001--Account Absent
Computer:
3011 001YC 000
Printer:
01 Nov 2004-13:50:51-01/02-SG -01-1-001--Account Present
Computer:
3011 001YK 000
Printer:
01 Nov 2004-13:50:51-01/02-SG -01-1-001--IDcde IncResp
Computer:
1011 001 A 0A
Printer:
01 Nov 2004-13:50:51-01/02-SG -01-1-001--IDcde Restore
Computer:
1011 001 R 0A
