Appendix B - System III Internal Status Messages
0RRLLL[#0000|NYYZZZZ]: RR is the receiver number of the CPM3, and LLL will be 000 to signify a CPM3 event, ss is the
shelf number, oo is the slot number.
CPM3 Internal Status Messages:
Description Printer Message Automation
Message (YYZZZZ)
LCD Message
Shelf 1 PSU3 Failure PSU 1 Failed AT0000 PSU 1 FAIL
Shelf 1 PSU3 Restoral PSU 1 Restored AR0000 N/A
Shelf 2 PSU3 Failure PSU 2 Failed AT0001 PSU 2 FAIL
Shelf 2 PSU3 Restoral PSU 2 Restored AR0001 N/A
PSU3 Inter-Connect Cable Failure PSU Cable Failed AT0100 PSU CABLE FAIL
PSU3 Inter-Connect Cable Restoral PSU Cable Restored AR0100 N/A
DC/DC3 A Shelf 1 Failure DCA 1 Failed YP0100 DCA 1 FAIL
DC/DC3 A Shelf 1 Restoral DCA 1 Restored YR0100 N/A
DC/DC3 B Shelf 1 Failure DCB 1 Failed YP0101 DCB 1 FAIL
DC/DC3 B Shelf 1 Restoral DCB 1 Restored YR0101 N/A
DC/DC3 A Shelf 2 Failure DCA 2 Failed YP0200 DCA 2 FAIL
DC/DC3 A Shelf 2 Restoral DCA 2 Restored YR0200 N/A
DC/DC3 B Shelf 2 Failure DCB 2 Failed YP0201 DCB 2 FAIL
DC/DC3 B Shelf 2 Restoral DCB 2 Restored YR0201 N/A
Battery Low Shelf 1 12V Battery 1 Low YT0100 BATTERY 1 LOW
Battery Low Restoral 1 12V Battery 1 Restored YR0100 N/A
Battery Low Shelf 2 12V Battery 2 Low YT0200 BATTERY 2 LOW
Battery Low Restoral 2 12V Battery 2 Restored YR0200 N/A
Fan Circuit Shelf 1 Failure Fan Circuit 1 Failed YX0100 FAN 1 FAIL
Fan Circuit Shelf 1 Restoral Fan Circuit 1 Restored YZ0100 N/A
Fan Circuit Shelf 2 Failure Fan Circuit 2 Failed YX0200 FAN 2 FAIL
Fan Circuit Shelf 2 Restoral Fan Circuit 2 Restored YZ0200 N/A
TCP/IP Shelf 1 Printer Failure TCP/IP 1 Printer Failed VZ0100 TCP 1 PRINTER FAIL
TCP/IP Shelf 1 Printer Restoral TCP/IP 1 Printer Restored VY0100 N/A
TCP/IP Shelf 2 Printer Failure TCP/IP 2 Printer Failed VZ0200 TCP 2 PRINTER FAIL
TCP/IP Shelf 2 Printer Restoral TCP/IP 2 Printer Restored VY0200 N/A
Parallel Shelf 1 Printer Failure Parallel 1 Printer Failed VZ0101 PAR 1 PRINTER FAIL
Parallel Shelf 1 Printer Restoral Parallel 1 Printer Restored VY0101 N/A
Parallel Shelf 2 Printer Failure Parallel 2 Printer Failed VZ0201 PAR 2 PRINTER FAIL
Parallel Shelf 2 Printer Restoral Parallel 2 Printer Restored VY0201 N/A
