28
When this option is programmed as '01', if 11 or 12-digit
DTMF is received, it will be decoded as SCANTRONICS
Format.
Option [A1]: FBI RS-232 - Default [01]
To enable the computer for FBI Super Fast protocol, pro-
gram Option [A1] as '01'. When enabled, the computer
output will be as indicated below:
Where:
J = FBI protocol identifier
RR = receiver number
LLL = line number
s = spaces
AAAA = account code
T = zone type
ZZ = zone number, in hex.
E = event code
if E = 0 and T = 0 : listen in.
Option [A2]: Digit Replace - Default [00]
Option 77 works in conjunction with Option A2. Option
77 is programmed with an ASCII value that will replace
an account code digit or insert a value into an account
code. Option A2 is used to replace a digit or insert a
digit. To replace a digit use 0x where x is the digit to be
replaced. To shift a digit use Option A2 and set to 8x
where x is the location in the account code.
Option [A3]: D6500 RS-232 - Default [00]
This option is used to strip hex digits on the automation
output. The DRL3 will emulate the Radionics 6500 RS-
232 protocol on pulse formats, Ademco Express and
Varitech only. When Option A3 is set to 01 the hex digit
will be stripped for 1-digit reporting codes including
Varitech 4/1.
Example 1: Code 1
Computer output: 1RRLLLsssssss022sAsss1
Example 2: Code B
Computer output: 1RRLLLsssssss022sOssss
If Option A3 set to 02: the hex digit will be stripped for
2-digit reporting codes including Varitech 4/2.
Example 1: Code 21
Computer output: 1RRLLLsssssss022sAss21
Example 2: Code B1
Computer output: 1RRLLLsssssss022sOsss1
If Option A3 set to 03: the hex digit will be stripped for 1
and 2-digit reporting codes including Varitech.
If Option A3 set to 04: the hex digit will be stripped for
BFSK.
NOTE: This option will only work if Option A4 is set
to 01.
Example 1: Code 21
Computer output: 6RRLLLsssssss022sAss21
Example 2: Code B1
Computer output: 6RRLLLsssssss022sOsss1
If Option A3 is set to 05: the hex digit will be stripped for
1-digit reporting and BFSK.
If Option A3 Is set to 06: the hex digit will be stripped for
2-digit reporting and BFSK.
If Option A3 set to 07: the hex digit will be stripped for
1-digit, 2-digit and BFSK.
NOTE: Option [70] must be left as an individual event
code when enabling this option.
Option [A4]: BFSK RS-232 - Default [00]
When programming Option [A4] as '00', the BFSK format
will be reported as Radionics 6500 BFSK mode to the
computer; the protocol identifier will be a 6.
Example 1: Code 21
Computer Output: 6RRLLL 022sAsss1
Example 2: Code B1
Computer Output: 6RRLLL 022sOsss1
When Option A4 set to 01, the BFSK will be reported as
a standard 3/1 extended format, the protocol identifier
will also be changed from 6 to 1.
Example 1: Code 21
Computer Output: 1RRLLL 022sAss21
Example 2: Code B1
Computer Output: 1RRLLL 022sOssB1
Option [A5]: Sescoa Super Speed - Default [01]
If set to 00 Sescoa Super Speed will be disabled and 4/2
with checksum will be enabled.
If set to 01, Sescoa Super Speed will be enabled and 4/2
with checksum will be disabled.
If set to 03 Sescoa Super Speed will be disabled and only
4/2 with checksum will be enabled. 4/2 double round will
be disabled.
Option [A6]: ITI Adjust - Default [00]
When set to 01, the ITI account codes will be converted
to four digits by stripping the last digit off. For example,
a panel account of 23459 will become account 2345. If
the leading digit of the panel account is a 0 than it will be
stripped and replaced with a space. For example, if
02349 is sent then the receiver will output 234 for the
panel account.
Option [A7]: Silent Knight FSK2 RS-232 - Default [00]
The DRL3 provides two possible outputs to the com-
puter for Silent Knight FSK2 format. The operation of this
option is explained below:
Options [A8] - [AF]: Dial-out Number For 2-way Audio
Transfer - Default [00]
These 8 options are used to provide the dial-out number
if the user wishes to transfer the call to another exten-
sion. Up to 16 digits may be programmed including any
'Feature Command' digits. The values in these options
will be sent as DTMF tones on the phone line after the
following sequence takes place:
00
00
01
01
Incoming Format
11-digit DTMF
12-digit DTMF
11-digit DTMF
12-digit DTMF
Decoded Format
Acron 3-8
Acron 4-8
Scantronics 2-8-1
Scantronics 3-8-1
JRRLLLssssssAAAATZZEss[DC4]
[A7] = 00 SKFSK disabled
[A7] = 01 SKFSK enabled for:
SKFSK1
ERRLssssssAAAAYYssss[DC4]
SKFSK2 Protocol #2
CRRLssssAAAAAAYYZZss[DC4]
[A7] = 02 SKFSK enabled for:
SKFSK1
ERRLssssssAAAAYYssss[DC4]
SKFSK2 Protocol #2
FRRLssssAAAAAAYYZZss[DC4]
