Functional Part Overview Functional Part Overview
3.3
3.4
A B C
D
E
F
Park the motorcycle only on a flat firm
surface, otherwise the motorcycle could
fall over and cause damage.
CAUTION
A. Headlight
For headlight replacement,Please refer to"Mainte-
nance" on page 10.14.
B. Battery Charging Port
For description and operation, Please refer to
"Power Management" on page 8.2.
C. Tail Light
For tail light replacement, Please refer to
"Maintenance" on page 10.14.
D. Chain Adjuster
Located on left and right side. Please refer to
"Maintenance" on page 10.12.
E. Side Stand Switch
This switch is a safety sensor that prevents
misoperation when the side stand is down.
F. Side Stand
The side stand supports the motorcycle when
parked. The key switch should be in the OFF
position when parked.
