1. Insert the key into the Battery Compartment
Lock A and turn the key counterclockwise to
unlock.
2. Open the Battery Compartment Cover B
3. Turn off the main power switch C.
4. Hold down the button D, follow the arrow to
remove the discharge plug.
5. Remove the battery pack upward in the
direction of the arrow.
Starting and Operating Starting and Operating
7.7
7. 8
A
B
Rebound Damping
Adjust the rebound damping by turning the knob
B at the top of the right front fork. The symbol "+"
means increasing rebound damping, and the
symbol "-" means decreasing rebound damping.
Turn the adjusting knob B clockwise in the "+"
direction to increase the rebound damping,
resulting in slower rebound speed.
Turn the adjusting knob B counterclockwise in the
"-" direction to decrease the rebound damping,
resulting in faster rebound speed.
The preload and rebound damping should
be adjusted properly according to the
road conditions and the weight of the
rider. Avoid adjusting the damping to the
maximum limit, otherwise it may cause
the front fork malfunction or even serious
injury.
CAUTION
The appearance of front fork may vary in
different brands, please refer to the actual
product.
NOTE
Please check and calibrate the air cham-
ber pressure regularly. Recommended
value: 80-100 PSI.
NOTE
Preload
Adjust the preload by turning the knob A on the
top of the left front fork. The symbol "+" means to
increase the preload, and the symbol "-" means to
decrease the preload.
Turn the adjusting knob A clockwise in the "+"
direction to increase the preload.
Turn the adjusting knob A counterclockwise in the
"-" direction to decrease the preload.
Front Fork Adjustment
For any adjustable knob to be adjusted to
the full, it should be adjusted one space
back after reached the end space.
CAUTION
To Next Page
