CHASSIS 5-5
SEAT
• Remove the seat 1 by using the ignition key.
DOCUMENT TRAY
• Remove the seat. (! 5-5)
• Remove the document tray 1.
FRAME COVER
• Remove the seat. (! 5-5)
• Remove the passenger grab handle 1.
• Disconnect the brake light/taillight coupler 2.
• Remove the frame covers 3 (left and right side).
