8-4 GSF600Y (2000-MODEL)
COMBINATION METER
REMOVAL
• Remove the headlight with two screws.
• Disconnect the socket 1 and coupler 2.
• Remove the lead wires from the two clamps and disconnect the
all lead wire couplers.
• Remove the headlight housing 3 by removing the headlight
housing bolts.
