ELECTRICAL SYSTEM 6-13
• Remove the bearing retainer 1.
• Remove the bearing 2, washer 3 and spacer 4.
• Remove the oil seal 5.
INSPECTION
ROTOR BEARINGS
Inspect the rotor bearings for abnormal noise. Also, rotate the
rotor bearings by hand and make sure that they rotate smoothly.
If there is anything unusual, remove the bearing(-s) using the
special tool.
##
##
# 09913-60910: Bearing remover
"
The removed bearing(-s) should be replaced with a new
one.
