Suzuki GSF600SK2 2002 - Front Brake Hose Routing

SERVICING INFORMATION 7-17
Master cylinder
Throttle cable
42˚
42˚
42˚
45 ± 5˚
14˚
14˚
After touching the brake hose union
to the stopper, tighten the union bolt
to the specified torque.
5˚
21˚
Throttle cable
21˚
21˚
5˚
Brake hose No. 1
Brake hose No. 2
Clamp
Brake caliper
After touching the brake hose union
to the stopper, tighten the union bolt
to the specified torque.
FRONT BRAKE HOSE ROUTING
