CHASSIS 5-15
• Remove the protector
4.
• Remove the front fork cap bolt
5, spring seat
6, spacer
7,
washer
8 and fork spring
9.
)
• Invert the front fork and stroke it several times to drain out fork
oil.
• Hold the front fork in the inverted position for a few minutes to
allow the fork oil to fully drain.
• Remove the dust seal
0 and oil seal stopper ring
A.
• Remove the cylinder bolt
B using the special tools.
% 09940-34520: T-Handle
09940-34531: Attachment (A)
Hold the front fork cap bolt when removing it, or it will
jump out due to the spring pressure.
