7-22 SERVICING INFORMATION
IGNITION COIL INSTALLATION
SPARK PLUG CAP INSTALLATION
Frame
#4
#1
#3
#2
F
W
D
FWD
Plug cap
Plug cap cover
FWD
FWD

Table of Contents

Questions and Answers:

Suzuki GSF650S Specifications

General IconGeneral
Engine Type4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke65.5 mm x 48.7 mm
Compression Ratio11.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Displacement656 cm³
Front BrakesDisc
Rear BrakesDisc
Front Tire120/70ZR17
Rear Tire160/60ZR17
Fuel Tank Capacity19 liters
Seat Height790 mm
