Suzuki GSF650S - Engine Components Removable with Engine in Place

3-2 ENGINE
ENGINE COMPONENTS REMOVABLE WITH ENGINE IN PLACE
The parts listed below can be removed and reinstalled without removing the engine from the frame. Refer to
page listed in each section for removal and reinstallation instructions.
ENGINE CENTER
ENGINE LEFT SIDE
ENGINE RIGHT SIDE
ITEM REMOVAL INSPECTION INSTALLATION
Exhaust pipe/muffler !3- 5 ---------- !3-8
Oil hoses !3-12 ---------- !3-84
Oil filter !3-12 ---------- !3-84
Oil cooler !3-6 !3-90 !3-8
Oil pan !3-21 !3-87 !3-69
Engine oil pressure regulator !3-87 !3-87 !3-88
Oil sump filter !3-87 !3-87 !3-88
Carburetors !4-15 !4-20 !3-10
Cam chain tensioner adjuster !3-13 !3-28 !3-82
Cylinder head cover !3-12 !3-30 !3-83
Camshafts !3-13 !3-26 !3-79
Cylinder head !3-14 !3-29 !3-78
Cylinder !3-14 !3-39 !3-77
Pistons !3-15 !3-40 ! 3-76
Starter motor !3-16 !6-24 !3-75
Generator !3-16 !6-15 !3-75
PAIR system !3-12, 97 !3-97 !3-85, 98
ITEM REMOVAL INSPECTION INSTALLATION
Gearshift lever !3- 4 ---------- !3-10
Engine sprocket cover !3- 4 ---------- !3-9
Engine sprocket/drive chain !3-4 !2-13 !3-9
Gear position switch !3-20 !6-27 !3-69
Starter clutch cover !3-17 ---------- !3-74
Starter idle gear !3-19 ---------- !3-70
Starter clutch !3-20 !3-45 !3-70
ITEM REMOVAL INSPECTION INSTALLATION
Clutch cover !3 -1 6 ---------- !3-73
Signal generator !3-16 !6-33 !3-74
Oil pressure switch !3-16, 89 !6-40 ! 3-74
Clutch plates !3-17 !3-43 !3-72
Clutch sleeve hub !3-18 ---------- !3-72
Oil pump driven gear !3-19 ---------- !3-71
Generator/oil pump drive gears !3-18 ---------- !3-71
Primary driven gear !3-18 ---------- !3-72
Gearshift shaft !3-19 !3-45 !3-71
Gearshift pawl/cam driven gear !3-1 9 ---------- !3-70
