Suzuki GSX-R600 User Manual

1G-8 Fuel System:
Fuel Tank Construction
B837H11706007
1
2
3
4
“A”
“B”
“B”
“B”
I837H1170032-02
1. Fuel tank heat shield
: Aluminum film side should face the engine side.
3. Fuel tank front bracket “A”: Insert to the fuel tank heat shield bracket.
2. Fuel tank front cover 4. Velcro fastenings
: Clean the adhesive surface before
adhering the velcro fastenings.
“B”: Apply adhesive agent.

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
