5. Engine Removal
5-3
Engine removal
Remove body cover.
Remove the spark plug cap from the spark plug.
Remove the fuel output and the vacuum tubes
from fuel pump.
Remove the oil control cable from oil pump.
Remove the oil tube from oil pump and then clip
the tube.
Remove the wire couplers of auto by starter and
ACG.
Remove the upper parts of the carburetor from its
upper side.
Remove the carburetor heater electric wire.
Vacuum tube
Fuel output tube
Wire couplers
Spark plug
Carburetor
upper parts
Heater wire
Oil tube
Control cable
