10. Brake System
Mechanism Diagram-Disk Brake 10-1
Mechanism Diagram-Drum Brake
···················································10-2
Precautions in Operation ········10-3
Troubleshooting·······················10-4
Disk Brake System Inspection10-5
Brake Fluid Replacement / Air Bleed
···················································10-6
Brake Caliper····························10-7
Brake Disk·································10-9
Brake Master Cylinder ·············10-9
Brake Drum·······························10-12
Brake Shoe ·······························10-12
Brake Panel·······························10-13
10
Mechanism Diagram - Disk Brake
3.3~3.7kgf-m
3.3~3.7kgf-m
1.5~2.0kgf-m
4.0~4.5kgf-m
10-1
To Next Page
