To this chapter contents
12. Rear Wheel / Rear Cushion
Swingarm
12-14
Removal
Remove the swingarm pivot bolt nut.
Remove the exhaust pipe, rear wheel, drive
chain, drive sprocket, drive chain cover and
rear cushion.
Remove the rear brake torque link.
Pull out the swingarm pivot bolt.
Remove the swingarm.
Inspection
Check the swingarm for wear or damage.
Nut×1
Nut×1
Pivot bolt
