Lubrication / Clutch / Transmission
Mechanism Diagram-Lubrication
System ....................................... 4-1
Mechanism Diagram-Clutch /
Transmission.............................4-2
Precautions in Opeartion .........4-3
Troubleshooting........................4-4
Engine Oil ..................................4-5
Engine Oil Strainer Cleaning....4-5
Oil Pump Removal / Inspection4-6
Oil pump Assembly / Installation
....................................................4-9
Clutch Disassembly..................4-12
Clutch Inspection......................4-13
Clutch Installation.....................4-14
Gear Shift Linkage Mechanism 4-16
4
Mechanism Diagram-Lubrication system
Rocker
arm
Camshaft
Transmission gear
main shaft
Transmission gear
sub shaft
Inner oil route
Con. Rod
Crankshaft
Centrifugal
oil strainer
Engine oil
strainer
Oil pump
4-1
