4
、
Lubrication / Clutch / Transmission
4-6
Oil Pump Removal / Inspection
Drain all the engine oil.
Disassemble the kick-starter, exhaust muffler
Disassemble the kick-starter lever (bolt×1)
Remove the engine R case(bolts×11)。
Remove the centrifugal oil strainer cover.
(screw×3)。
Remove the centrifugal oil strainer anti-loosen
nut, and remove the oil strainer.
Special tool：
Centrifugal oil strainer special nut socket:
SYM-9023100-SY125
Screw×3
Bolt×11
Clutch cable
Bolt×1
Anti-loosen nut
