11. Steering / Front Wheel / Front Fork
Remove the front fender (boltx4).
11-16
Remove the front fork bolt from the steering
stem and remove the front fork.
Oil seal inspection / replacement
Push the fork pipe for several times to check if
there is any oil leakage or excessive noise.
Check if there is any scratch on the fork pipe if
oil leakage happens.
Replace the front fork if there is a scratch on
the fork pipe.
If there is oil leakage but without scratch on
the fork pipe, replace the oil seal.
Pour out the fork fluid.
Remove the oil seal stopper ring and then
remove the old oil seal.
Caution
y Do not damage the fork pipe when
removing the oil seal.
2 bolts for both sides
Bolt for both sides
Scratch
Stopper ring
