To this chapter contents
11. Steering / Front Wheel / Front Fork
Wolf Classic 125 R
11-19
Install the fork pipe from the bottom of the
front fork. Align the fork pipe cap with the
steering handlebar.
Hold the fork pipe by hand and tighten the
front fork upper bolt and nut.
Tighten the fork bolt on the steering stem.
Torque value：3.0~3.5kgf-m
Tighten the front fork upper bolt and nut and
confirm the specified torque value.
Torque value：3.0~3.5kgf-m
Tighten the left / right handlebar.
Torque value：3.0~3.5kgf-m
Handlebar
Fork pipe cap
Bolt
Top bridge
Fork pipe
Boltx1
Bolt, nut
Bolt×2
