12. Rear Wheel / Rear Cushion
Loosen the drive chain adjusting nut.
12-4
Adjusting nut
Loosen the driven flange nut.
Insert a screw driver into the rear wheel axle
and fix the axle.
Remove the rear wheel axle nut.
Remove the rear wheel, side collar, drive
chain adjuster and rear brake panel after the
wheel axle is removed.
Axle nut
Flange nut
Adjusting nut
