13. Electrical System
13-21
Meter bulb replacement
Remove the main switch and meter assembly.
Remove the meter cover.
Pull out the indicator bulb with bulb seat.
Replace the indicator bulb if it is burned out.
Specification：
Winker indicator bulb 12V 1.7W
High beam indicator bulb 12V 1.7W
Neutral indicator bulb 12V 1.7W
Meter illumination bulb 12V 1.7W
Fuel indicator bulb 12V 1.7W
Installation
Install in the reverse order of removal.
Nut×4
Tachometer
Illumination bulb
Indicator bulb
Illumination bulb
Screw×1
Speedometer
