3. Fuel System
3-5
Remove the carburetor fuel tube. Loosen the
clamp from the air- cleaner side, and unplug
the fuel tube. Remove the carburetor holding
nuts.
Remove the carburetor.
Installation
Install as the reversed order of removal
procedures.
Torque value：
Carburetor holding nuts: 0.7~1.1kgf-m
After installation, the following adjustment is
required:
● Throttle cable free play.
● Idle speed adjustment.
Adjust screw
Lock nut
Fuel tube
Carb holding screw ×2
A/F clamp
