5. AC Generator / Starter Clutch
Precautions in Operation
General Information
z For engine troubleshooting and inspection, please refer to the first chapter.
z Starting Motor repairing process and cautions, please refer to Chapter 13
th
.
Specifications measurement：mm
Item Service Limit
Start Driven Gear exterior diameter
54.060
Starting Clutch interior diameter
54.940
Torque Value
Flywheel Bolt 5.0~6.0kgf-m
R crankcase cover bolts 0.8~1.2kgf-m
Starting clutch inner-hexagon bolts 1.0~1.4kgf-m with screw adhesive
Special Tool
Flywheel puller SYM-3111000
