6. Engine Removal
Settle the engine on a rack.
Remove the engine front hanger.
(Nut X 4)
6-6
Remove the engine rear holding bolts.
(Nut X 2, bolt X 2)
Remove the engine upper holding nut.
(Nut X1, bolt×1)
Pull out the bolt and remove the engine.
Nut×4
Nut×1
Nut×2
