Symbol DIGITAL DS6708 - GS1 Databar (Formerly Reduced Space Symbology); GS1 Databar-14; GS1 Databar Limited

To Next Page

To Previous Page

Symbologies 13 - 65

GS1 DataBar (formerly Reduced Space Symbology)

The variants of GS1 DataBar are DataBar-14, DataBar Expanded, and DataBar Limited. The limited and expanded

versions have stacked variants. Scan the appropriate bar codes to enable or disable each variant of GS1 DataBar.

GS1 DataBar-14

Parameter # F0h 52h.

GS1 DataBar Limited

Parameter # F0h 53h.

*Enable GS1 DataBar-14

(01h)

Disable GS1 DataBar 14

(00h)

*Enable GS1 DataBar Limited

(01h)

Disable GS1 DataBar Limited

(00h)
