15 - 16 Symbol DS6708 Digital Scanner Product Reference Guide

Code Types (continued)

UPC/EAN Composites

GS1 DataBar and GS1-128 Composites

Aztec

Aztec Rune

NOTE When selecting composite bar codes, enable AIM IDs if parsing UPC or EAN composite data, or data from

an application that uses symbol separators.
