Only one signal input A or B can be connected to all 12 outputs at any time. The front panel LEDs and
CLI show which of the two signal inputs are connected to the outputs.
As there are many inputs, fault lines, and auto-switch changeover conditions, the auto-switch logic is
rather complex. To learn more about the operations and features of the 9611B, see the following:
l CLI to interact with the 9611B auto-switch logic
l Operations and features
l Simple task examples
9611B_UserGuide_RevA.pdf.......................................................................... Page 9
