l 1 each, 3-pin Form C alarm connector, labeled N. O., COMMON and N. C., and collectively
labeled ALARM (push-in terminals). Note: the terminals' labels should match the position of
the contacts when the relay is in its energized (no alarm) state.
Dimensions
l Height: 1.725”
l Width: 16.98”
l Depth: 15.0"
l Weight 7lbs
Power Supply
The AC power supply has been selected so that no fans are required for continuous operation in the
specified temperature range.
AC Power Supply
Power requirements: 100 - 240V, 50/60 Hz, 20W
