Specifications
AM IRIG timecode
Frequency 1PPS to 10MPPS
Level 0-6Vp-p
Modulation Frequency Up to 1MHz
Code Format Any IRIG Format, IEEE 1344, NASA 36, 2137, XR3
Impedance 50Ω or 1kΩ
Outputs
Connector (12): 50ΩBNC Female
RF
Frequency 100Hz to 10MHz
Level 1V rms (15dBM max)
Gain Jumper selectable -3dB, +1.5dB, + 2.5dB
Harmonic <-40dBc
Non-Harmonic <-80dBc
Load Impedance 50Ω
Isolation >80dB
Additive Phase Noise
Measured at 10 MHz, +10 dBM input level
1Hz -125dBc
10Hz -135dBc
100Hz -135dBc
1kHz -145dBc
10kHz -155dBC
Pulse/DC IRIG
Frequency 1PPS - 10MPPS
Level 5V peak
Rise Time <20ns
Fall Time <20ns
Jitter <200ps rms
Skew <+/-2ns output to output
Load impedance 50Ω
Page 38 ..........................................................................9611B_UserGuide_RevA.pdf
