AM IRIG Timecode
Frequency 1PPS to 10MPPS
Level 0-6Vp-p
Modulation Frequency Up to 1MHz
Code Format Any IRIG Format, IEEE 1344, NASA 36, 2137, XR3
Load Impedance 50Ω
Alarm Input
Normal State 2.2 to 5.0 V (TTL High) Configured via CLI.
Can be High or Low
Alarm State <0.8 V (TTL Low)
Connectors BNC
Qty 2 (1 for A input & 1 for B input)
Enable/Disable Confgiured via CLI. Default is disabled
9611B_UserGuide_RevA.pdf.......................................................................... Page 39
