Tasks
9611B Bootloader CLI
Use the following two procedures to upgrade the DSP and the FPGAprogram images. These oper-
ations cannot be achieved using the front panel controls. Use the command line interface for the fol-
lowing procedure.
1. In the main user interface, enter reset <CR>
Display shows the following:
" Press any key to halt boot."
2. Press any key, to bring up the following display
*******************************************************************************
** Welcome to the 9611B Bootloader CLI **
** **
** Press 'h' or '?' for menu. **
*******************************************************************************
3. Press the "h" key to bring up the following display:
*******************************************************************************
** Welcome to the 9611B Bootloader CLI **
** **
** Press 'h' or '?' for menu. **
*******************************************************************************
boot - Boot application, (A, B, or active).
setpart - Set the active boot partition (A or B).
getpart - Get the current active boot partition.
reset - Reset/reboot the system.
upgdsp - DSP software upgrade (A or B).
upgfpga - FPGA firmware upgrade.
version - Display bootloader version info.
logout - Exit the CLI.
h - This help, or help on a specific command
? - This help, or help on a specific command
How to Upgrade FPGA Program Image
Loading the FPGAprogram image is straightforward as there is only a single partition in which to load
the program image.
1. In the 9611B Bootloader CLI menu, enter upgfpga <CR>
2. Navigate to the location of the FPGA file and load it.
Page 34 ..........................................................................9611B_UserGuide_RevA.pdf
