120 S100 User Guide – Rev. D – June 2005
SyncServer S100
Pin Descriptions
Operating & Storage
Environments
Temperature and Humidity 0°C to +45°C/5-95% @ 40°C
Options Long Antenna Cable (Belden 9913), Lightning Arrester, High-gain GPS Antenna,
GPS In-Line Amplifier, Rack Mount Slides
P1: Ethernet RJ45
Description: 8-pin Phone Jack,
Mfr: AMP, Part # 555153-1
Pin Number Description
1TX (+)
2TX (-)
3RX (+)
4N/C
5N/C
6RX (-)
7N/C
8N/C
P3: Serial A (Data Terminal Port/DTE)
Description: 9-pin “D” Plug, Mfr: AMP, Part #
869436
Pin Number Description
1 RS-232 Data Carrier Detect (in)
2 RS-232 Receive Data (in)
3 RS-232 Transmit Data (out)
4 RS-232 Data Terminal Ready
(out)
5Ground
6 RS-232 Data Set Ready (in)
7 RS-232 Request to Send (out)
8 RS-232 Clear to Send (in)
9 RS-232 Ring Indicator (in)
S100 Data Sheet Specifications
Component Specifics Description
