Figure 5-2(2)
5-13
ALTIMETER CORRECTION
(Alternate Static Source)
5-13
CONDITIONS:
MSL
COCKPITVENTILATION OFF
EXAMPLE:
FLAPS 0°
INDICATEDAIRSPEED 90 KIAS
ALTIMETERCORRECTION -50 ft
SECTION 5
PERFORMANCE
Feb 25, 2005
CORRECTION TO BE
ADDED - FEET
KIAS
60
-10
80
-40
70
-25
90
-50
100
-70 -70
110
-90
-110
-130 -145 -165
120
130
140
150
160
NOTES:
1. INFLUENCE OF VENTILATION: WITH THE COCKPIT VENTILATION OPEN
(ONE OR TWO FRESH AIR NOZZLES), ADD TO THE VALUES IN THE
“CORRECTION TO BE ADDED” COLUMN +5 ft.
2. INFLUENCE OF THE CABIN HEAT IS FOUND TO BE NEGLIGEABLE.
