Symphony SA-160 - Drain Valves

AIRCRAFT
SA 160
AIRCRAFTA I R C R A F T
Symphony
Figure 7-11
Drain Valves
2
3
4
3x
1
addition, the gascolator, located on the lower left front of the firewall,
has also a drain, which is accessible from the bottom of the cowling
section.
The fuel should be checked daily before the first flight while
performing the preflight checks and after each refueling to check for
water or sediment contamination. Fuel contamination check can be
done by using a sampler cup. Make sure that enough fuel has been
drainedtoensurethatallwaterandsedimenthasbeenremoved.
SECTION 7
DESCR. & OPERATION
Feb 25, 2005
7-36
