Symphony SA-160 - Rate of Climb

AIRCRAFT
SA 160
AIRCRAFTA I R C R A F T
Symphony
5-18
SECTION 5
PERFORMANCE
EXAMPLE:
WEIGHT 1990 lbs
PRESSUREALTITUDE MSL
AIRTEMPERATURE 15°C
THE EXAMPLE WEIGHT IS 50% OF THE
DIFFERENCE BETWEEN 1830 LBS AND 2150
LBS. BETWEEN THE READ VALUES OF CLIMB
Figure. 5-7
RATE OF CLIMB
CONDITIONS:
FLAPS0°
FULLTHROTTLE
NOTE: LEANMIXTURE ASPERLYCOMINGO-320INSTRUCTIONS AT 5000FTAND ABOVE.
RATES FOR GIVEN WEIGHTS, THE
CORRESPONDING PERCENTAGE IS
TOBE CONSIDERED.
CLIMBSPEED 80 KIAS
RATE OF CLIMB 838 ft/min
PRESS
ALT
ft
WEIGHT
lbs
CLIMB
SPEED
~KIAS
RATE OF CLIMB ~ FT/MIN
ISA
-10 °C
ISA
ISA
+20 °C
ISA
+10 °C
ISA
+30 °C
MSL
2000
4000
6000
8000
10000
12000
MSL
2000
4000
6000
8000
10000
12000
14000
2150
1830
80 740 710 680 655 630
78 645 615 590 560 535
76 550 520 495 470 445
74 455 425 400 375 350
73 365 340 315 290 270
73 270 245 220 195 175
73 175 150 130 105 -
80 995 965 930 900 870
78 890 860 830 800 770
76 790 755 725 700 670
74 685 655 625 600 570
73 590 560 535 510 485
73 485 460 430 410 385
73 380 355 330 310 285
73 270 250 225 205 185
Feb 25, 2005
