Symphony SA-160 - Baggage Compartment; Seats and Seat Belts

AIRCRAFT
SA 160
AIRCRAFTA I R C R A F T
Symphony
7-16
7.21 SEATS AND SEAT BELTS
SECTION 7
DESCR. & OPERATION
WARNING !
The aircraft cabin provides side-by-side seating for two. The seats are
adjustable fore and aft. To position the seat, lift the handle located below
theseatframe, slide the seat into position, and release the handle. Ensure
thattheseatislockedinto position.
The seats are equipped with automatic, four point seat belts/shoulder
harness assemblies. To fasten the seat belts/shoulder harness a center
link is used. The design incorporates an inertia reel system for the
shoulder portion. The shoulder harnesses are attached to the cage truss
structure behind the seats, and allows for complete freedom of
movement of the upper torso area. In the event of a sudden deceleration,
thereelslockuptoprovidepositiverestraintfortheuser.
Feb 25, 2005
7.19 BAGGAGE COMPARTMENT
The baggage compartment in the SA 160 is located behind the seats. A
baggage door is provided on the left side of the aircraft just behind the
pilot'sdoor.
During flight the baggage should be properly secured at all time. For this
purpose four cargo tie-downs located on the baggage compartment
floorboardandtwosmallcargonetsareprovided.
Maximum weight in the baggage compartment is limited to 165 lbs. (75
kg) however the maximum baggage compartment floor load for each
baggagearea(redmarking)islimitedtoamaximumof99lbs(45kg).
Do not place any small loose articles in the baggage compartment.
All baggage must be stowed in containers such as packs, suitcases
or bags to avoid potential injuries in the event of a forced landing.
