Figure 5-8
TIME, FUEL,AND DISTANCE TO CLIMB
CONDITIONS:
WEIGHT975KG (2150 LBS)
FLAPS0°
FULLTHROTTLE
FUEL MIXTURE AS RECOMENDED BY LYCOMING
O-320 LEANING SCHEDULE
ZERO WIND, ISA
NOTE: 1. ADD 4.0 l (APPROX. ONE GALLON) OF FUEL FOR START, TAXI AND TAKEOFF.
FOR TEMPERATURES ABOVE STANDARD, INCREASE VALUES BY 10% FOR
EVERY 10 °C.
2.
EXAMPLE:
DEP. AIRFIELD PRESSURE ALTITUDE 2000 ft
DEP. AIRFIELD TEMPERATURE 11 °C
CRUISE PRESSURE ALTITUDE 6000 ft
TIME: 10.9 min - 3 min = 7.9 min.
FUEL: 1.95- 0.58 = 1.37 U.S.Gal.
DIST. : 14.5 NM-4 NM = 10.5 NM
PRESSURE
ALTITUDE
ft
CLIMB
SPEED
KIAS
FROM SEE LEVEL
TIME
min
FUEL USED
DISTANCE
N.M.
U.S.
GAL.
l
1000 79 1,5 1,0 0,26 1,9
2000 78 3,0 2,2 0,58 4,0
3000 77 4,7 3,4 0,90 6,3
4000 76 6,6 4,6 1,21 8,7
5000 75 8,6 6,0 1,58 11,5
6000 74 10,9 7,4 1,95 14,5
7000 73 13,3 8,9 2,35 17,8
8000 73 16,1 10,6 2,80 21,5
9000 73 19,3 12,4 3,28 25,9
10000 73 23,2 14,5 3,83 31,0
11000 73 27,8 17,0 4,49 37,8
12000 73 33,7 20,0 5,28 46,6
