SA 160
AIRCRAFTA I R C R A F T
Symphony
AIRCRAFT
7-11
7.9 INSTRUMENT PANEL
7.11 FLIGHT INSTRUMENTS
Feb 25, 2005
SECTION 7
DESCR. & OPERATION
Flight instruments are standard and arranged around the basic “T”
configuration. Those are the airspeed indicator (top left), the attitude
indicator (top), the altimeter (top right), the turn coordinator (lower
left), the directional gyro (center below) and the vertical speed
indicator (lower right).
Theinstrument panel of the SA 160 is shown in Fig.7-4.
For an easy and quick reference, the instruments and controls are clearly
dividedinthreesections:leftcentreandrightsections
Theleftsectioniscomprised of a group of six flight instruments located in
front of the pilot (for further details se Fig 7-4). Below the flight
instrument is a row of switches for system command.
The middle section of the panel contains the avionics equipment. The
avionics equipment type is depended upon the configuration of the
aircraft (i.e. VFR or IFR version). Below the avionics equipment is the
throttle,mixtureandcarburetorheat.
On the center console pedestal is located the flap switch and next to it
the light dimmer switches. On the lower part of the pedestal are the heat
controls, the fuel shut-off valve, the primer and the parking brakecontrol
buttons.
TheVM 1000 Engine Management System indicatoris on the right side of
the avionics column. It shows the manifold pressure, the engine speed,
oil temperature, oil pressure, cylinder head temperature, exhaust gas
temperature, fuel pressure, as well as alternator output amperage and
voltage of the electrical system. The circuit breakerpanel is located on the
extremeright side of the panel.
