Symphony
overall lighting for the instrument panel. In the event of an
instrument light failure, the map light is sufficient to light all the
instruments and controls required for safe flight and landing by
night.
The map light system is controlled and dimmed through the
instrument light dimmer switch (labeled “MAP LIGHT”) located
rightsidetherowofswitchesbelowtheflightinstruments.
When the instrument light system is turned on the brightness of the
“Fuel Pump”, “Pitot HEAT” and “Flaps in Motion” annunciator lights
willbesimultaneouslyreduced.
In order to obtain the proper light intensity from the warning lights
the instrument light dimmer switch must be in the off position for
flight during the day.
Day/Night Function for Advisory Lights
CAUTION !CAUTION !
(b) Exterior Lighting
The aircraft has a combined navigation / strobe lights on each wing tip
as well as a landing light installed on the left side of the lower engine
cowling.
The exterior light control switches are located on the lower section of
theleftinstrumentpanelinfrontofthefirstpilot.
To activate the navigation lights, strobe light and landing light, the
respectiveswitchesmustbeplacedinthe“ON”position.
SECTION 7
DESCR. & OPERATION
Feb 25, 2005
7-46
