AIRCRAFT
SA160
AIRCRAFTA I R C R A F T
Symphony
4of11
SECTION 9
SUPPLEMENT 3
SECTION 2
LIMITATIONS
No change.
SECTION 3
EMERGENCY PROCEDURES
3.1 ABNORMAL PROCEDURES
(a) Failsafe Operation
A failsafe circuit connects the pilot's headset and microphone directly
to COM 1 in case the power is interrupted or the GMA 340 unit is
turned off.
SECTION 4
NORMAL PROCEDURES
4.1 POWERING ON THE GMA 340
Normal operating procedures are completely described in the GARMIN
GMA 340 Audio Panel Pilot's Guide, P/N 190-00149-10, Rev. A, or later
appropriaterevision.
TheGMA340Audio Panel is shown in figure 7-1.NOTE:
PILOT
To turn the unit on, rotate the left small knob clockwise past the
click.
Feb 25, 2005
