SA160
AIRCRAFTA I R C R A F T
Symphony
AIRCRAFT
5of11
SECTION 9
SUPPLEMENT 3
Feb 25, 2005
4.2 SELECT A TRANSCEIVER
Press either COM 1 MIC, COM 2 MIC, or COM 3 MIC button for
selection of either COM 1, COM 2, or COM 3 for both MIC and
audiosource. The active com audio is always heard on the headphones.
Additionally, each audio source can be selected independently by
pressing COM 1, COM 2, or COM 3 . When selected in this way,
they remain active as audio sources regardless of which transceiver has
beenselectedformicrophoneuse.
4.3 SELECT THE INTERCOM MODE
ToactivateotherthenALLmode,press or button.
Pressagain to deactivate the mode.
The operator can switch directly from PILOT to CREW or from CREW to
PILOT by pressing the other mode button. TheALL mode is active when
neitherPILOTnorCREWLEDarelit.
4.4 ADJUSTING INTERCOM VOLUME
AND SQUELCH
(a)LEFT SMALL KNOB - Unit ON/OFF power control and pilot
ICS volume. Full counterclockwise detent position is OFF
PILOT
PILOT
CREW
COMx
MIC
COMx
COMx
