SECTION 9
SUPPLEMENT 3
(b)LEFTLARGEKNOB -PilotICS mic VOXsquelchlevel.
Clockwise rotation increases the amount of mic audio (VOX level)
required to break squelch. Full counterclockwise is the "HOT MIC”
position.
(c) RIGHT SMALL KNOB - Copilot ICS volume.
(d)RIGHTLARGE KNOB - Copilot mic VOX squelch level.
Clockwise rotation increases the amount of mic audio (VOX level)
required to break squelch. Fully counterclockwise is the "HOT MIC”
position.
Audio level is always controlled be the selected COM or NAV
radiovolume.
NOTE:
4.5 SELECT SPLIT COM MODE
Press the COM 1/2 button to activate the Split COM function.
When this mode is active, COM 1 is dedicated solely to the pilot for
MIC/audio while COM 2 is dedicated to the copilot for MIC/ audio. The
pilot and copilot can simultaneously transmit in this mode over separate
radios.BothpilotscanstilllistentoCOM3,NAV 1, NAV 2, DME, ADF,and
MKR as selected. The Split COM mode is canceled by pressing the COM
1/2button asecondtime.
4.6 SELECT A NAV AUDIO SOURCE
Press NAV 1, NAV 2, DME, ADF , or MKR to select
eachaudiosource. A second button press deselects the audio.
NAVx
DME ADF
MKR
MUTE
COM
1/2
COM
1/2
PILOT
COPILOT
COPILOT
Feb 25, 2005
