Symphony SA-160 - Endurance Profile

SA 160
AIRCRAFTA I R C R A F T
Symphony
AIRCRAFT
ENDURANCE ~ HOURS
Figure 5-11
PRESSURE ALTITUDE ~ FEET
CONDITIONS:
WEIGHT 975 kg (2150 lbs), INITIAL FUEL
LOADING 110LITERS(29.1 U.S.GAL.)USABLE
ZEROWIND, ISA
LEAN MIXTURE UP TO 75% POWER FOR BEST
ECONOMYAND ADJUSTFULLRICH ABOVE75%.
ENDURANCE PROFILE
NOTE:
ENDURANCE INCLUDES FUEL FOR START, TAXI, CLIMB AND DESCENT WITH 45
MINUTES RESERVE AT CRUISE POWER, AND TIME FOR CLIMB.
2000
4000
6000
8000
10,000
12,000
2
1,5
2,5
3
3,5
4
80% BHP
70% BHP
60% BHP
Full Throttle
5-23
SECTION 5
PERFORMANCE
Feb 25, 2005
