Symphony SA-160 - Static and Pitot Pressure System Schematic

SA 160
AIRCRAFTA I R C R A F T
Symphony
AIRCRAFT
Figure 7-16
Static and Pitot Pressure System Schematic
Static Pressure
Static-Port 2
Static-Port 1
Pitot Pressure
Blind Encoder
Alternate Static Source
(from inside of cabin)
Pitot Tube
Drain Valves
Air Speed Indicator
Altimeter
Valve
To Transponder
Vertical Speed Indicator
IFR
SECTION 7
DESCR. & OPERATION
7-49
Feb 25, 2005
