Thisoccursatlowamperagelevelsofapproximatelyless than 2 amps.
The voltmeter is integrated in the VM 1000 Engine Management
System. The voltage supplied to the aircraft electrical system is
displayed on the VM 1000 indicator in the lower right area both
graphicallyanddigitally(SeeFig.7-5).
If the BAT switch is ON (without further accessories) approximately
25Vwillbeindicated.
When the engine is operating and the electrical power supply system
isfunctioningproprely, approximately26-28 V should be indicated.
Additionally the system has a built-in warning that is coupled with
the EC 100. When the system voltage is out of nominal range ( 26 - 28
V),eithertolow or to high, the EC 100 will automatically begin to flash
therespectivewarningandapulsingaudiotonewillbepresent.
indicated.
Additionally the system has a built-in warning that is coupled with
the EC 100. When the system voltage is out of nominal range ( 26 - 28
V),eithertolow or to high, the EC 100 will automatically begin to flash
therespectivewarningandapulsingaudiotonewillbepresent.
Voltmeter
Circuit Breakers
The circuit breaker panel is located on the extreme right side of the
instrument panel (SeeFig.7-15).
