(c) NavData Card Slots
TherearetwodatacardslotsonthefaceoftheGNS430.
The Jeppesen NavData card should be inserted in the left-most slot. The
secondslotisprovidedforfutureoptionsandexpansion capabilities.
Insert the card with the swing arm handle at the bottom and the label
facingtoleft.
16 of 16
SECTION 9
SUPPLEMENT 1
(b) Screen Areas
WPT
DTK
DIS
GS
COM
Window
Data
Fields
NAV
Window
Map Display
Map Page
Map Scale
Present Position
Desired Track
Figure 7-2
Screen Areas (Map Page)
