(c) NavData Card Slots
TherearetwodatacardslotsonthefaceoftheGNC420.
The Jeppesen NavData card should be inserted in the left-most slot. The
secondslotisprovidedforfutureoptionsandexpansion capabilities.
Insert the card with the swing arm handle at the bottom and the label
facingtoleft.
(b) Screen Areas
COM
Window
User
Selectable
Data Field
Map Scale
WPT
DTK
ETE
DIS
COM
GS
TERM
01:12
Figure 7-2
Screen Areas (Map Page)
Map Display
Map Page
Desired Track
Present Position
Data
Fields
